LoRa Certification Testing Laboratory

What is LoRa?

LoRa is a type of LPWAN communication technology that provides an ultra-long-range wireless transmission solution based on spread spectrum technology. This solution redefines the traditional trade-off between transmission distance and power consumption. With features such as long range, low power consumption (long battery life), support for multiple nodes, and low cost, LoRa is increasingly being applied in areas like industrial monitoring, the Internet of Things (IoT), and secure network transportation.

Currently, LoRa mainly operates in globally license-free frequency bands, including 433 MHz, 470 MHz, 868 MHz, and 915 MHz. Below are some examples of regional frequency allocations:

- European Union

- Frequency Bands: 863–870 MHz, 433.175–434.665 MHz

- Bandwidth: 125 kHz

- Mandatory Channel Frequencies: 868.10, 868.30, 868.50 MHz; 433.175, 433.375, 433.575 MHz

- United States

- Frequency Band: 902–928 MHz

- Bandwidth: 125 kHz / 500 kHz

- China

- Frequency Bands: 779–787 MHz, 470–510 MHz

- Bandwidth: 125 kHz

- Mandatory Channel Frequencies (779–787 MHz): 779.50, 779.70, 779.90 MHz

- Australia

- Frequency Band: 915–928 MHz

- Bandwidth: 125 kHz / 500 kHz

- New Zealand

- Frequency Band: 915–928 MHz

- Bandwidth: 125 kHz

- South Korea

- Frequency Band: 920–923 MHz

- Bandwidth: 125 kHz

- Mandatory Channel Frequencies: 922.10, 922.30, 922.50 MHz

- India

- Frequency Band: 865–867 MHz

- Bandwidth: 125 kHz

- Mandatory Channel Frequencies: 865.0625, 865.4025, 865.985 MHz

- Russia

- Frequency Band: 864–870 MHz

- Mandatory Channel Frequencies: 868.9, 869.1 MHz

JJR Laboratory China provides comprehensive testing for LoRa modules and gateway products across all of the above technical specifications.

As a nationally accredited third-party laboratory with dual certifications from CNAS and CMA, JJR Laboratory leverages over 20 years of experience in the inspection and testing industry and a professional wireless team to offer LoRa product manufacturers comprehensive and one-stop certification services.
